2020 Mustang Engine Information – 227 cubic inch V6 (5.2L Ford Predator V8)
The Predator V8
The Predator is a 5.2-liter, supercharged V8 engine from Ford Motor used to power sports cars like the Ford Mustang Shelby GT500. Featuring a dual overhead cam (DOHC) design, in a V configuration, the Ford Predator architecture has been part of the Ford Modular family since 2019.
This engine is hand-built and was specifically designed for the Shelby GT500 for the 2020 model year. Contrary to the 5.2L Voodoo engine that powers the Shelby GT350, the Predator doesn’t utilize a flat plane crankshaft. Ford stipulates that such a configuration wasn’t necessary due to the significant power bumps created by the supercharger. The Ford 5.2L Predator engine is the most powerful production engine ever built by the Ford Motor Company.
Engine Basics
| Model Year | 2020 |
|
Engine Name & Year
|
5.2L 760hp V8 (GT500) |
|
Standard / Optional
|
|
|
Engine Short Name
|
5.2L 760hp V8 (GT500) |
|
Engine Configuration
|
V8 |
| Cylinders | 8 |
| VIN Code | 9.5:1 |
|
Displacement (CU)
|
315 Cubic Inches |
|
Displacement (Liters)
|
5.2 Liters |
| Fuel | Supercharged |
| Compression | 625 lb-ft @ 5,000 rpm |
| Power (hp) | 760 hp @ 7,300 rpm |
| Torque (lb/ft) | 625 lb/ft |
Engine Info
| Metric | Value |
|---|---|
| Engine family | Modular |
| Displacement | 5.2 liters |
| Aspiration | Supercharged |
| Configuration & cylinders | V configuration, eight cylinders |
| Vehicle engine orientation | Longitudinal |
| Valve configuration | Dual overhead cam (DOHC) with variable camshaft timing (VCT) |
| Assembly sites | Romeo, Michigan |
| Predecessor | Ford 4.6L V8 |
| Successor | Currently none |
More Specifications
| METRIC | VALUE |
|---|---|
| Bore | 94 mm |
| Stroke | 93 mm |
| Compression ratio | 9.5:1 |
| Max boost | 12 psi |
| Max power @ RPM | 760 hp @ 7,300 rpm |
| Max torque @ RPM | 625 lb-ft @ 5,000 rpm |
| Cylinder head | Cast aluminum |
| Cylinder block | Cast aluminum |
| Camshaft drive | Chain |
2020 Mustang Engine Information & Specs – 315 Ford Predator V8 (5.2L)
×VIN Code 9.5:1
○VIN Code J
