2011 Ford Mustang Mechanical Information & Drawings

Axle Information

Axle code on B pillar Axle ratios & type
BB 3.73
CC 2.73 Locking mandatory on GT automatic transmissions
DD 3.55 locking Std. on manual transmissions
GG 3.31
YY 3.15

Brake Information

Ford Racing sells a SVT Front Brake Upgrade Kit that radically improves stopping. It can be bought for about $1200 .

The Ford Racing SVT brake kit includes massive 4-piston calipers manufactured by Brembo.

The bolt-on SVT front brake upgrade kit includes a pair of 4-piston black anodized Brembo calipers, two high performance 14″ vented rotors, front and rear brake pads, and Goodrich DOT-approved stainless steel brake lines. Please note that the included Goodrich stainless steel brake lines fit the included Shelby GT500 calipers only.

The Ford Racing SVT front brake upgrade kit is designed for use with ABS-equipped 2005-2014 Mustangs only, including the GT, V6, Bullitt, GT/CS, and Shelby GT. Requires 18″ or larger rims for proper clearance. Fits V6 05, 06, 07, 08, 09, 10, 11, 12, 13, 14. Also fits GT’s for the years 05, 06, 07, 08, 09, 10, 11, 12, 13, 14 as well as 08 and 09 Bullitt’s and the 2010 & 13 Bosses.

Technical Notes. This kit will not fit any of the Bullitt wheels or the FR500 wheels. It will fit the 18×9 GT4 and 18×9.5 Shelby GT500 wheels designed for the 2005+ Mustangs. This kit requires the use of 18″ or larger rims for clearance, and all other styles should be test fit to ensure proper fitment. It will only fit ABS equipped Mustangs.


Electrical Information

Exhaust Information

Although these images may look alike, there are differences in pipe diameter, muffler numbers, tips and hangars. As I add this additional information, to the images, they will diverge.

2011 Mustang V6 exhaust

2011 Shelby GT500 exhaust

2011 Shelby GT500 exhaust

Transmission Information

Vacuum Information

Wheel and Tire Information
